  • FR4 Multilayer HDI PCB For Mobile Phone PCB Manufacturer in Germany
FR4 Multilayer HDI PCB For Mobile Phone PCB Manufacturer in Germany

FR4 Multilayer HDI PCB For Mobile Phone PCB Manufacturer in Germany

FR4 Multilayer HDI PCB For Mobile Phone PCB Manufacturer in Germany



Quick detail:

Material:Fr4

Layer:4

Surface   finish:immersion gold

Copper   weight:1oz

Board   size:4.5*3cm

Total   thickness:1.6mm

Min   line width and space:3mil

Min   hole: 0.15mm

Name:High   density Interconnector printed circuit boards


HDI PCB information:

HDI is an abbreviation of High Density Interconnector . It is a kind of circuit board which uses micro blind buried hole technology. HDI is a compact product designed for small-capacity users.

Microvias are used as the interconnects between layers in high density interconnect (HDI) substrates and printed circuit boards (PCBs) to accommodate the high input/output (I/O) density of advanced packages. Driven by portability and wireless communications, the electronics industry strives to produce affordable, light, and reliable products with increased functionality. At the electronic component level, this translates to components with increased I/Os with smaller footprint areas (e.g. flip-chip packages, chip-scale packages, and direct chip attachments), and on the printed circuit board and package substrate level, to the use of high density interconnects (HDIs) (e.g. finer lines and spaces, and smaller vias).



IPC standards define microvias as blind or buried vias with a diameter equal to or less than 150 μm. With the advent of smartphones and hand-held electronic devices, microvias have evolved from single-level to stacked microvias that cross over multiple HDI layers. Sequential build-up (SBU) technology is used to fabricate HDI boards. The HDI layers are usually built up from a traditionally manufactured double-sided core board or multilayer PCB. The HDI layers are built on both sides of the traditional PCB one by one with microvias. The SBU process consists of several steps: layer lamination, via formation, via metallization, and via filling. There are multiple choices of materials and/or technologies for each step.



Microvias can be filled with different materials and processes:filled with epoxy resin (b-stage) during a sequential lamination process step; filled with non-conductive or conductive material other than copper as a separate processing step; plated closed with electroplated copper; screen printed closed with a copper paste. Buried microvias are required to be filled, while blind microvias on the external layers usually do not have any fill requirements.A stacked microvia is usually filled with electroplated copper to make electrical interconnections between multiple HDI layers and provide structural support for the outer level(s) of the microvia or for a component mounted on the outermost copper pad.



HDI PCB application:

Electronic design continues to improve the performance of the whole, while also trying to reduce its size. From mobile phones to smart weapons, small portable products, "small" is always the same pursuit. High-density integration (HDI) technology can make the end product design more compact, while meeting the electronic performance and efficiency of higher standards. HDI is widely used in mobile phones, digital cameras, MP3, MP4, computers, automotive electronics and other digital products, among which the most widely used mobile phones. HDI board generally used to build-up manufacturing, the more the number of layers, the higher the technical grade plate. Ordinary HDI board is basically a laminated, high-level HDI with 2 or more layers of technology, while using stacked holes, electroplating fill, laser drilling and other advanced direct PCB technology. High-end HDI board is mainly used in 3G mobile phones, advanced digital cameras, IC board and so on.



Advantages of HDI PCB:

Can reduce the cost of PCB

Increased Line Density: Interconnecting Traditional Boards to Parts

With better electrical performance and signal correctness

Reliability is better

Can improve the thermal properties

Can improve the radio frequency interference / electromagnetic interference / electrostatic discharge (RFI / EMI / ESD)

Increase design efficiency



Parameter technology of HDI PCB:

Feature

Technical   specification

Number of   layers

4 – 22 layers standard, 30 layers   advanced

Technology   highlights

Multilayer boards with a higher   connection pad density than standard boards, with finer lines/spaces, smaller   via holes and capture pads allowing microvias to only penetrate select layers   and also be placed in surface pads.

HDI builds

1+N+1, 2+N+2, 3+N+3,4+N+4, any layer in   R&D

Materials

FR4 standard, FR4 high performance,   Halogen free FR4, Rogers



Copper weights   (finished)

18um – 70um

Minimum track   and gap

0.075mm / 0.075mm

PCB thickness

0.40mm – 3.20mm

Maxmimum   dimensions

610mm x 450mm; dependant upon laser   drilling machine

Surface   finishes available

OSP, ENIG, Immersion tin, Immersion   silver, Electrolytic gold, Gold fingers

Minimum   mechanical drill

0.15mm

Minimum laser   drill

0.10mm standard, 0.075mm advanced
